Optical Fiber Ribbon Cable

Ribbon cable are more and more popular, small volume and lightOur Ribbon cable till to 24core indoor

Product Details

Description

Ribbon cable are more and more popular, small volume and light

Our Ribbon cable till to 24core indoor

We used all Muliti-mode fiber are from Germany is J-fiber, Here you can see our fiber stock, we control the quality 100% and test them 100% from the raw material to final finished products.

Structure&Capability

Structure
Description	Optical Fiber Ribbon、Inner Jacket、Strength Member、Outer Jacket.
Fiber	SM: G652D、G655、G657 Or other single-mode optical fibers. MM: A1a、A1b Or other multi-mode fibers.
Strength Member	Aramid yarn or other high strength yarn.
Jacket	Materials: low smoke halogen-free flame retardant polyolefin (LSZH) or other materials Color: Color as specified by standard or other color.
Features
Application	Used as cable in indoor premises distribution system. used for MPO active adaptor. Used for transmission between indoor transmission equipment and voice data processing optical interface device.
Characteristic	Good mechanical and environmental performance. Flame retardant (or non-flame retarding)characteristic meets the requirements of relevant standards. Mechanical and physical properties of jacket meet the requirements of relevant standards. Soft, flexible, easy to lay and splice, and with big capacity data transmission.
Temperature	-20℃～+60℃
Parameter
Fiber Count	Cable Dimension (mm)	Cable weight (kg)	Tensile (N)		Crush (N/10cm)		Bending radius (mm)
Fiber Count	Cable Dimension (mm)	Cable weight (kg)	Long Term	Short Term	Long Term	Short Term	Static	Dynamic
4	3.5×2.5	8.4	100	200	300	1000	10D	20D
6	4.0×2.5	9.3	100	200	300	1000	10D	20D
12	5.0×2.5	12.0	130	440	300	1000	10D	20D
24	7.5×2.5	15.2	200	660	300	1000	10D	20D
