Duplex Flat Indoor Fiber Optic Cable

Description

Bare Fiber、Coating、tight-buffer、strength member、jacket

Fiber

SM：G652D、G655、G657 Or other single-mode optical fibers.
MM：A1a、A1b Or other multi-mode fibers.

Tight-buffer

Tight-buffered Ф0.6mm、Ф0.7mm、Ф0.9mm

Strength Member

Aramid yarn or other high strength yarn.

Jacket

Materials: Flame - retardant polyvinyl chloride ( PVC ) , low - smoke halogen - free flame - retardant polyolefin ( LSZH) , flame - retardant polyethylene ( ZRPE ) or other materials.
Color: Color as specified by standard or other color.

Features

Application

Used as pigtails and patch cords.
Used in optical communication equipment rooms.
Optical connection of Optical Distribution frame.
Used in indoor cabling.

Characteristic

Good mechanical and environmental performance.
Flame retardant (or non-flame retarding)characteristic meets the requirements of relevant standards.
Mechanical and physical properties of jacket meet the requirements of relevant standards.
Soft, flexible, easy to splice, and with big capacity data transmission.

Temperature

-20℃～+60℃

Parameter

Fiber Count

Cable Dimension (mm)

Cable weight
(kg)

Tensile (N)

Crush (N/10cm)

Bending radius (mm)

Long Term

Short Term

Long Term

Short Term

Static

Dynamic

2

1.6×3.3

5.7

80

150

100

500

10D

20D

1.85×3.8

6.9

80

150

100

500

10D

20D

2.0×4.1

7.4

100

200

100

500

10D

20D

2.8×5.7

13.2

150

300

100

500

10D

20D

3.0×6.1

14.0

150

300

100

500

10D

20D
