Indoor SM Dry Structure Fiber Optic Cable

● 10production line for this micro module indoor cable● Capacity: about 100km/ days● Max. 288core we can produce

Product Details

Advantages

● 10production line for this micro module indoor cable

● Capacity: about 100km/ days

● Max. 288core we can produce

● UL certificate/CPR Dca certificate

● More than 10years production experience and export experience

Structure&Capability

Structure
Description	Color Coating Fiber、Strength Member、Cable Sub-unit、Tape、Jacket
Fiber	SM: G652D、G655、G657 Or other single-mode optical fibers. MM: A1a、A1b Or other multi-mode fibers.
Strength Member	Aramid yarn or other high strength yarn.
Jacket	Materials: flame retardant polyvinyl chloride (PVC), low smoke halogen-free flame retardant polyolefin (LSZH), flame-retardant polyethylene (ZRPE) or other materials. Color: Color as specified by standard or other color.
Features
Application	Used as pigtails and MPO patch cords. Used as connection of optical distribution frame. Used as access building cable in premises distribution system, especially used in indoor or outdoor aerial access cabling.
Characteristic	Good mechanical and environmental characteristic. Flame retardant (or non-flame retarding)characteristic meets the requirements of relevant standards. Small size, light weight, soft, flexible, easy to lay and splice, suitable for data center, office buildings and other optical fiber use intensive places to use. Big capacity data transmission.
Temperature	-20℃～+60℃
Parameter
Fiber Count	Cable Dimension (mm)	Cable Weight (kg)	Tensile (N)		Crush (N/10cm)		Bending radius (mm)
			Long Term	Short Term	Long Term	Short Term	Static	Dynamic
48	8.0	54.0	300	600	300	1000	10D	20D
