288F Air Blown Micro Fiber Optic Cable

Product Details Structure&Capability Options Cable Dimension: The nominal cable dimension, or other customized dimension. Delivery Length: 1.0km or 2.0km, or other customized length. Other requirement

Product Details

Product Details

Structure&Capability


Structure

Description

Loose tube made of color coating fibers and filled with waterproof compounds.Loose tube stranded around the non-metallic strength member which in the central of cable into cable core, The gap in the cable core is filled with water-blocking filling compound. a layer of water-blocking tape is longitudinal wrapped around the cable core, then a layer of jacket extruded.

Fiber

SM: G652D、G655、G657 Or other single-mode optical fibers.
MM: A1a、A1b Or other multi-mode fibers.

Jacket

Material: high Density polyethylene (HDPE), PA or other materials.
Color: black or other colors.

Features

Application

Suitable for duct blowing laying, suitable for application in backbone network, metropolitan area network and access network.

Characteristic

Light weight, small friction, moderate hardness, suitable for blowing laying.
The tension of the cable is more uniform and smaller during the laying process, which avoids the secondary damage of the cable.
The laying process is simplified, the laying speed of cable is fast, the span is long, and the laying cost is greatly reduced.
The laying distance is long, the intermediate joint is reduced, and the loss is reduced.
Can be blown into the cable in batches with the increase of communication traffic,reduce the high cost of multiple destructive excavations.
Cables can be blown out to facilitate the replacement of new ones to maintain the technical lead.

Temperature

-40℃~+60℃

Parameter

Fiber Count

Cable Dimension(mm)

Cable weight
(kg)

Tensile(N)

Crush(N/10cm)

Bending Radius(mm)

Long Term

Short Term

Long Term

Short Term

Static

Dynamic

1~6

2.5




150

450

10D

20D

7~12

3.0




150

450

10D

20D

13~24

4.0




150

450

10D

20D

1~36

5.5

28.5

40.0

140.0

150

450

10D

20D

36~72

6.0

36.0

54.0

180.0

150

450

10D

20D

2889.418015050015045010D20D





Options


Cable Dimension: The nominal cable dimension, or other customized dimension.

Delivery Length: 1.0km or 2.0km, or other customized length.

Other requirements: other customized special request.
