48F Riser Cable

Product Details Advantages Our No.1 sales products We sell it to the French Telecom company ORANGE and Israel Telecom We loaded it by full container with the pallet, better protection.We care very det

Product Details

Advantages

Our No.1 sales products

We sell it to the French Telecom company ORANGE and Israel Telecom

We loaded it by full container with the pallet, better protection.We care very details.

High quality and reasonable prices

30 years quality warranty

Structure&Capability

Structure
Description	Tight-buffered fiber、strength member、jacket
Fiber	SM: G652D、G655、G657 Or other single-mode optical fibers. MM: A1a、A1b Or other multi-mode fibers.
Strength Member	FRP
Jacket	Materials: low smoke halogen-free flame retardant polyethylene (LSZH) or other materials Color: Color as specified by standard or other color.
Features
Application	Used as access building cable in premises distribution system，Especially suitable for indoor vertical cabling. Floor optical branch. Used in access network or as cable Vertical cabling in customer premises network.
Characteristic	Good mechanical and environmental performance. Flame retardant (or non-flame retarding)characteristic meets the requirements of relevant standards. Mechanical and physical properties of jacket meet the requirements of relevant standards. Soft, flexible, easy to lay and splice, and with big capacity data transmission
Temperature	-20℃～+60℃
Parameter
Fiber Count	Cable Dimension (mm)	Cable Weight (kg)	Tensile (N)		Crush (N/10cm)		Bending radius (mm)
Fiber Count	Cable Dimension (mm)	Cable Weight (kg)	Long Term	Short Term	Long Term	Short Term	Static	Dynamic
4～12	8.5	71	100	200	300	1000	10D	20D
24	10.5	99	100	200	300	1000	10D	20D
36	12.5	123	100	200	300	1000	10D	20D
48	13.5	146	100	200	300	1000	10D	20D
