Product Details
Indoor Fiber Optic Drop Cable Clamp-ACC
Material: Nylon plus fiber glass.
Product Property: The plastic anchoring clamp is suitable for insulated low-voltage ABC cable. It is also suitable for multiple conductors.
Easy installation and perfect indsulated function. It is in accordance with the NFC 33-042
Specifications
1. For insulated low-voltage ABC cable
2. For multiple conductors
3. Nylon plus fiber glass
4. Fast delivery
Minimal Breaking Load Testing | ||||
Test Parameters | ||||
1 | The object of test | ACC | ||
2 | Customer | / | ||
3 | Reason of the test | Confirmation of quality | ||
4 | Test kind | Control | ||
5 | Test equipment | Testing machine ZD-4 No.279\30, certificate No.2\ 2013. | ||
6 | Sample quantity | 2 | ||
7 | Mathed of sampling | Samples from the current batches | ||
8 | Test procedure | Static load balancing at a speed of 5mm/min until compete fracture | ||
9 | Tempreture conditions | Room tempreture: 25，Humidity: 60% | ||
Test result | ||||
Test product | Used accessories | MBL,KN | Broken details | The Conclusion |
ACC | 4MM Drop cable | 1.5kn | Plastic broken | The product meet the specofications requrements and approved for usage |
