FTTH Flat Optical Fiber Indoor Cable

Description

Color Coating Fiber、Strength Member,Jacket

Fiber

SM: G652D、G655、G657 Or other single-mode optical fibers.
MM: A1a、A1b Or other multi-mode fibers.

Strength Member

FRP or steel wire.

Jacket

Materials: flame retardant polyvinyl chloride (PVC), low smoke halogen free flame retardant polyolefin (LSZH) or other materials.
Color: Color as specified by standard or other color.

Features

Application

Used as terminal connection in FTTH access network.
Used for building horizontal cabling in premises distribution system, especially suitable for horizontal cabling and terminal quick connection.

Characteristic

Good mechanical and environmental performance.
Excellent side pressure protection design.
Flame retardant (or non-flame retarding)characteristic meets the requirements of relevant standards.
Soft, flexible, easy operation, and with big capacity data transmission.

Temperature

-20℃～+60℃

Parameter

Fiber Count

Cable Dimension（mm）

Cable weight
（kg）

Tensile (N)

Crush (N/10cm)

Bending radius (mm)

Long Term

Short Term

Long Term

Short Term

Static

Dynamic

1～4

2.0×3.0

8.0

40/100

80/200

500/1000

1000/2200

10H

20H

1～4

2.0×3.0

9.0

40/100

80/200

500/1000

1000/2200

10H

20H
