2x16 Block Type Splitter SC/APC

● Low insertion loss, Low PDL and High reliability● High return loss and Good repeatability● Wide wavelength range

Product Details

Features

● Low insertion loss, Low PDL and High reliability

● High return loss and Good repeatability

● Wide wavelength range

● Excellent channel-to-channel uniformity


Applications

● LAN, WAN and Metro Networks

● FTTH project & FTTX Deployments

● CATV System

● GPON, EPON

● Fiber Optic Test Equipment

● Data-base Transmit Broadband Net


Encapsulation Size

Item

2x16

Size of metal case (mm)

80*12*4

Input/Output(mm)

0.9

Fiber length(M)

1.5


Specifications

Item

2x16

Fiber Type

G657A1

Working Wavelength

1260nm~1650nm

Standard Insertion Loss (dB)

≤14.6

Uniformity (dB)

≤1.5

PDL (dB)

≤0.3

Wavelength Dependent Loss (dB)

≤1.5

Return Loss (dB)

≥55

Directivity (dB)

≥55

Operating Temp. Gange

-40℃~ +85℃
